LINKEX™ WF-300XL LED FLOODLITE
Made in United Kingdom
Contact for pricing
Available in Saudi Arabia
The Linkex™ WF-300 ® XL LED Floodlite is a high performance, robust, lightweight and portable ATEX LED floodlight for use in potentially explosive atmospheres. With its innovative and patented light engine, it delivers an outstanding level of white light and is fully compliant with the latest ATEX and IECEx standards, including OP IS - optical intrinsic safety.
Specifications
| Product Reference | WF-300 ® XL | |
| Product Description | LinkEx™ LED Floodlite | |
| Code | II 2 G D Ex eb mb IIC T4 Gb Ex tb IIIC T118°C Db | |
| Type of Protection | 'eb' increased safety 'mb' encapsulation 'tb' enclosure protection | |
| Area of Classification | Zones 1 and 2, Gas Groups IIA, IIB and IIC | |
| Temp. Classification | T4 | |
| Area of Classification (Dust) | Zones 21 and 22, Dust Groups IIIA, IIIB and IIIC | |
| Max Surface Temp (Dust) | T118°C | |
| Ambient Temperature | -40°C to +55°C | |
| Certificate | CML 18ATEX3372X IECEx CML 18.0198X | |
| Voltage | 18-50V AC / DC | 90-264V AC / DC |
| Power | 55w | 62w |
| Enclosure | Marine grade aluminium alloy, epoxy powder coated | |
| Lens | Toughened Glass | |
| Beam Type | Medium Flood | |
| Light Source: | Type | 36 x White High Power LEDs |
| Life | 100,000+ hrs | |
| Output at LED Source (Lumens | Up to 9,200 | |
| Weight | 7.3kg (excluding cable) | |
| Ingress Protection | IP66/67 | |
| Accessories | Supplied with bridle and lamp stand |
