LINKEX™ LED TEMPORARY LUMINAIRE
Made in United Kingdom
Contact for pricing
Available in Saudi Arabia
The LinkEx™ LED Temporary Luminaire is a high powered LED Leadlamp for use in short-term lighting installations and maintenance tasks and is CE marked to the ATEX directive and IECEx certified for safe use in Zones 1 and 2 potentially explosive gas and dust atmospheres, where a T4 temperature class permits.
Specifications
| Product Reference | LX-400 | |
| Product Description | LinkEx LED ATEX Temporary Luminaire | |
| Product Description | T4 Low (LV) & High (HV) Voltage | |
| Code | Non-Linkable: II 2 GD Ex eb mb IIC T4 Gb (-20°C to +55°C) Ex tb IIIC T135°C Db IP67 Linkable*: II 2 GD Ex eb mb IIC T4 Gb (-20°C to +55°C) Ex tb IIIC T135°C Db IP66* | |
| Type of Protection | "eb" increased safety, "mb" encapsulation, "tb" enclosure | |
| Area of Classification (Gas) | Zones 1 & 2, Gas Groups IIA, IIB, IIC | |
| Temperature Class | T4 | |
| Area of Classification (Dust) | Zones 21 & 22 | |
| Max Surface Temp (Dust) | 135°C | |
| Ambient Temperature | -20°C to +55°C (+45°C with LX-621 Protective Cover fitted) | |
| Certificate | CML 18ATEX3371X IECEx CML 18.0197X | |
| Enclosure and Lens | Polycarbonate with Anti-static Coating | |
| Beam Type | Wide Angle, Diffused Area Light (180° or 360°) | |
| Light Source: | Type | LED |
| Light Source: | Life | Over 60,000 hrs |
| Light Source: | Power | 24VAC ≈27W (42VA) 48VAC ≈27W (51VA) HV ≈ 26W |
| Light Source: | Output | 4,000 lm (at source) |
| Input Voltage | LV 18-50V AC/DC HV 90-264V AC | |
| Weight (Non-linkable) | 3.0kg without cable | |
| Length (Non-Linkable) | 0.7m | |
| Ingress Protection | Non-Linkable (No Socket) IP67 / Linkable (Socket Fitted) IP66* | |
| Included | Supplied with lens protecting film (LX-545), protection cover kit (LX-621) and hanging straps (LX-654) |
