LINKEX™ WF-250XL LED FLOODLITE
Made in United Kingdom
Contact for pricing
Available in Saudi Arabia
The LinkEx™ WF-250XL LED Floodlite™ is designed to give the optimum level of light for working in smaller, hazardous area confined spaces from its innovative and patented light engine. Ideal for 24 volt applications with a limited power supply, up to 8 ATEX LED floodlights can be used in different strings from just one Wolf transformer.
Specifications
| Product Reference | WF-250XL | |
| Product Description | LinkEx™ LED Floodlite | |
| Code | II 2 G D Ex eb mb IIC T4 Gb Ex tb IIIC T118°C Db | |
| Type of Protection | 'eb' increased safety 'mb' encapsulation 'tb' enclosure protection | |
| Area of Classification | Zones 1 and 2, Gas Groups IIA, IIB and IIC | |
| Temp. Classification | T4 | |
| Area of Classification (Dust) | Zones 21 and 22, Dust Groups IIIA, IIIB and IIIC | |
| Max Surface Temp (Dust) | T118°C | |
| Ambient Temperature | -40°C to +55°C | |
| Certificate | CML 18ATEX3372X IECEx CML 18.0198X | |
| Voltage | 18-50V AC / DC | 90-264V AC / DC |
| Power | 28w | 31w |
| Enclosure | Marine grade aluminium alloy, epoxy powder coated | |
| Lens | Toughened Glass | |
| Beam Type | Medium Flood | |
| Light Source: | Type | 18 x White High Power LEDs |
| Light Source: | Life | 100,000+ hrs |
| Light Source: | Output at LED Source (Lumens) | Up to 4,788 |
| Weight | 5.4kg (excluding cable) | |
| Ingress Protection | IP66/67 | |
| Accessories | Supplied with bridle and lamp stand |
