LFX2 FLOODLITE
Made in United Kingdom
Contact for pricing
Available in Saudi Arabia
The LFX2 Floodlite™ is ideal for safely illuminating large sized Hazardous Areas that need wide, even, light coverage. ATEX, IECEx and UKEX certified for Zones 1, 2 and 21, 22, the LFX2 Floodlite™ is available with either 24 or 32 LEDs and with 4 different beam angles to suit a wide range of applications. IP66/67 certified with a full range of fixing accessories, the LFX2 Floodlite™ is ideal for safe use in both indoor and outdoor potentially explosive atmospheres.
Specifications
| Product Reference | LFX2S-24-50 | LFX2S-24-60 | LFX2S-32-50 | LFX2S-32-55 |
| Code | II 2 G D Ex eb mb IIC T4 Gb Ex tb IIIC T110 °C Db | |||
| Certification | ExVeritas 19 ATEX 0586X IECEx EXV 19.0079X ExVeritas 21 UKEX 0939X | |||
| Input Voltage Range | 88 - 140V AC; 180 - 277 VAC | |||
| Input Power | 135W | 90W | 180W | 120W |
| Frequency | 50 - 60 Hz | |||
| Power Factor | >0.95 | >0.95 | >0.95 | >0.95 |
| Enclosure Size | Large | |||
| Lumen Output (Max)* | 19,449 | 12,996 | 25,932 | 17,288 |
| LEDs | 24 LED | 24 LED | 32 LED | 32 LED |
| Beam Angles | Narrow (36°), Medium (45°), Wide (62°), Ultra Wide (102°) | |||
| Ingress Protection | IP66/IP67*** | |||
| Gas Temp. Class | T4 | |||
| Weight | 15.5kg | |||
| LOWER TEMP. LIMIT | -50°C | |||
| UPPER TEMP. LIMIT | 50°C | 60°C | 50°C+ | 55°C+ |
| Colour Temperature | 5000K |
