VENTURI CONES
Made in United Kingdom
Contact for pricing
Available in Saudi Arabia
Contact Us for Pricing & Availability
Chat on WhatsApp
Request a Quotation by Email
info@west-velocity.com
Available in
🇸🇦 Saudi Arabia
Pneumatic (compressed air) or saturated steam powered venturi cones for safe use in adverse or explosive atmospheres when used with optional static grounding cord.
Specifications
| Product Reference | VF-RV760S | VF-RV760 | VF-RV1500 |
| Materials | Anti-static, Polyethylene Cone | ||
| Dimensions (d/h) | 13 x 41 cm | 20 x 84 cm | 30 x 106 cm |
| Weight | 2kg | 3kg | 9kg |
| Inlet Connection | 12.7mm NPT | 25.4mm NPT | |
| Flange | API 76.2mm, (167mm BC) | API 152.4mm (167mm BC) | |
| 40PSIG Inlet Air | |||
| Free Air | 810 cfm (1,377 m³/hr) | 1,001 cfm (1,702 m³/hr) | 2,740 cfm (4,658 m³/hr) |
| Air Consumption | 22 cfm (37 m³/hr) | 59 cfm (100 m³/hr) | |
| Induction Ratio | 37:1 | 46:1 | 47:1 |
| 80PSIG Inlet Air | |||
| Free Air | 1,180 cfm (2006 m³/hr) | 1,439 cfm (2,446 m³/hr) | 3,329 cfm (5,659 m³/hr)) |
| Air Consumption | 58 cfm (99 m³/hr) | 124 cfm (211 m³/hr) | |
| Induction Ratio | 20:1 | 25:1 | 27:1 |
| Air Consumption and Horsepower Requirements for Air Compressor* | |||
| Air Pressure (PSIG) Inlet Air | 80 | ||
| Air Consumption scfm (m³/hr) | 58 (99) | 124 (211) | |
| Compressor Hp (PS) | 9.3 (9.43) | 19.8 (20.08) |
