ATEX SPLITTER BOX
Made in United Kingdom
Contact for pricing
Available in Saudi Arabia
Contact Us for Pricing & Availability
Chat on WhatsApp
Request a Quotation by Email
info@west-velocity.com
Available in
🇸🇦 Saudi Arabia
The Wolf ATEX Splitter Box is compact, portable and CE marked to the ATEX Directive for safe use in Zones 1 and 2 potentially explosive gas and Zones 21 and 22 dust* atmospheres, making it ideal for power distribution within hazardous area confined spaces.
Specifications
| Product Reference | LL-260 (Suffixes define cable type and length, plug socket and fuse options) | LL-260/SS (Suffixes define cable type and length, plug, socket and fuse options) |
| Product Description | ATEX GRP Splitter Box | ATEX Stainless Steel Splitter Box |
| Enclosure | GRP (Glass Reinforced Polyester) Enclosure with 316 Stainless Steel Skid | 316 Stainless Steel Enclosure with 316 Stainless Steel Skid |
| Approval Codes | II 2 GD Ex de IIC T5 Gb Ex tb IIIC T90°C Db IP66* -20°C - +50°C | |
| Type of Protection | "e" increased safety"d" flameproof | |
| Classification (Gas) | Zones 1 & 2 | |
| Gas Groups | IIA, IIB IIC | |
| Temperature Class (Gas) | T5 | |
| Classification (Dust) | Zones 21 & 22* | |
| Max. Surface Temp. (Dust) | 90°C* | |
| IP Rating | IP66* | |
| Ambient Temperature | -20°C to +50°C** | |
| Certificate | Baseefa12ATEX0268/IECEx BAS 16.0073X (Splitter Boxes fitted with ATX sockets are not IECEx certified) | |
| Voltage | Up to 254V AC | |
| Maximum Input Current | 15A*** | |
| Plug and Socket Types | ATX, CEAG, STAHL and Marechal | |
| Input Cable Types | SY, Ship's Braided or H07RN-F (HOFR) | |
| Weight | 10 KG (nominally)**** | 12 KG (nominally)**** |
