RIFTEK Stepped Hole ID Measurement System
Contact for pricing
Available in Saudi Arabia
Stepped hole ID measurement system for non-contact scanning of two through-holes with different diameters using rotating laser sensors. Precise inner diameter control with multi-stage measuring head. Supplied worldwide, including the USA, UK, Australia, Germany, Spain, Italy and India.
Details
| Manufacturer | RIFTEK EUROPE |
| Model / product | Stepped Hole ID Measurement System |
| Product group | KSA industrial |
| Type | Project system |
| Typical users | Machining shops |
Key benefits
- Measures two diameters in one setup
- No contact, no gauge wear
- Three lasers in one head
- Rugged IP67 housing
Key specifications
| 1st hole range | 15...40 mm |
| 2nd hole range | 50...70 mm |
| accuracy (1st hole) | ±0,02 mm |
| points per turn | 6400 |
RIFTEK in Saudi Arabia
West Velocity Company (Al Khobar) is the authorised RIFTEK distributor in Saudi Arabia. Ask for a quotation on WhatsApp +966 54 126 7359 or info@west-velocity.com.
