MIDI TORCH
Made in United Kingdom
Contact for pricing
Available in Saudi Arabia
The Midi Torch is a compact high power LED pocket torch delivering excellent illumination, robustness and reliability in the most extreme conditions and is CE marked to the ATEX directive and IECEx certified for safe use in Zones 0,1 and 2 potentially explosive gas and Zones 21 and 22 dust atmospheres.
Specifications
| Product Reference | M-85 | |
| Product Description | Primary Cell ATEX Midi Safety Torch with LED | |
| Code | Industrial | II 1G Ex ia IIC T3/T4 Ga IP67 II 2D Ex ib IIIB T200°C Db |
| Mining | I M1 Ex ia I Ma IP67 | |
| Type of Protection | 'ia' Intrinsic Safety | |
| Area of Classification (Gas) | Zone 0, Gas Group IIC | |
| Temp. Classification (Gas) | T3/T4 | |
| Area of Classification (Dust) | Zone 21 Dust Groups IIIB | |
| Max Surface Temperature (Dust) | 200°C | |
| Ambient temperature | -40°C to +40°C | |
| Certificate | Baseefa11ATEX0236X IECEx BAS 11.0116X | |
| Enclosure | Impact Resistant Thermoplastic | |
| Lens | Polycarbonate, Impact Resistant | |
| Beam Type | Narrow Spot with Wide Angle Fringe Light | |
| Light Source: | Type | High Power LED |
| Output | Up to 210 lm | |
| Life | 25,000+ hours (fitted for life) | |
| Power Source: | Part Number | TP-295 (4 x LR6 Cells) |
| Battery Type | LR6 Primary Cells, to IEC 60086, Alkaline AA | |
| Volts | 4 x 1.5v | |
| Light Duration | Up to 7 hours | |
| Ingress Protection | IP67 | |
| Weight (incl. battery) | 0.190Kg |
