BCH SC889100 Single Phase Solid State Relay (125A AC51, Capacitive Load)
Made in India
Contact for pricing
Available in Saudi Arabia
Contact Us for Pricing & Availability
Chat on WhatsApp
Request a Quotation by Email
info@west-velocity.com
Available in
🇸🇦 Saudi Arabia
BCH SC8 series single phase solid state relay for high voltage and capacitive load applications, 125A AC51 / 33 KVAR, zero-cross switching, main voltage 24-660V AC and control voltage 7-30V DC. Electronic switching of the load with no contact bounce or arcing, long electrical life (over 1000 million operations) and direct PLC compatibility.
Specifications
| Cat Code | SC889100 |
| Series | SC8 (high voltage and capacitive load application) |
| Phase | Single phase |
| AC51 Rating | 125 A |
| KVAR Rating | 33 |
| I²t (A²s) | 20000 |
| Non-Repetitive Max. Peak Voltage | 1600V |
| Control Voltage Range | 7-30V DC |
| Main Voltage | 24-660V AC |
| Switching | Zero-Cross |
| Max. Leakage Current (Nominal Voltage, 50 Hz) | 1 mA RMS |
| Operating Frequency Range | 0.1-440Hz |
| Input / Output Opto Isolation | 4000V |
| Max. Off-State Voltage Rise (dV/dt) | 500V/µs |
| Minimum Load Current | 5mA RMS |
| Standards | IEC 60947-4-2 for motor control & IEC 60947-4-3 for other loads; CE marked |
| Suggested Heat Sink Rth (K/W) by Ambient | 25°C: 0.3; 35°C: 0.3 |
| Dimensions | 44.5 x 58.2 mm, 27 mm depth (SC7 / SC8 / SC9) |
Typical Applications
Industrial heating and temperature control, motor control, capacitor control, transformer control, lamps control, solenoid control, air conditioning
Datasheet, certificates and quotation on request - info@west-velocity.com.
