RIFTEK RF659 Edge Sensor
Contact for pricing
Available in Saudi Arabia
Non-contact edge sensor for precise measurement and monitoring of edges on tapes, plates, substrates, and other objects. Operates on the optical shadow principle with LED and photo-detector array. Supplied worldwide, including the USA, UK, Australia, Germany, Spain, Italy and India.
Details
| Manufacturer | RIFTEK EUROPE |
| Model / product | RF659 Edge Sensor |
| Product group | Sensors - optical micrometers |
| Type | Standard model |
| Typical users | Strip / web lines |
Key benefits
- Shadow method, no contact
- Tiny, lightweight sensor heads
- Fast updates for line control
- Digital display and analog outputs
Key specifications
| accuracy | ±20 um |
| repeatability | 1 um |
| measurement range | 7 mm |
| result update rate | 1500 Hz |
RIFTEK in Saudi Arabia
West Velocity Company (Al Khobar) is the authorised RIFTEK distributor in Saudi Arabia. Ask for a quotation on WhatsApp +966 54 126 7359 or info@west-velocity.com.
Source: riftek.com
Brochure: PDF
🔦
