BCH BCHRCB300DPC25 Residual Current Circuit Breaker RCCB (2 Pole, 25A, 300mA)
Made in India
Contact for pricing
Available in Saudi Arabia
Contact Us for Pricing & Availability
Chat on WhatsApp
Request a Quotation by Email
info@west-velocity.com
Available in
🇸🇦 Saudi Arabia
BCH 2 pole residual current circuit breaker, 25A rated current with 300mA sensitivity, conforming to IS 12640 (Part 1) and IEC/EN 61008-1. It detects and trips against leakage current, protecting human life against electric shock and the electrical installation against fire. With 300mA sensitivity it is less sensitive, suitable for larger installations having high levels of leakage current. Finger proof IP20 terminals, dual termination for busbar or wire, and a test button for monthly checks.
Specifications
| Cat Code | BCHRCB300DPC25 |
| Description | RCCB DOUBLE POLE 25A - 300mA |
| Poles | 2 Pole, DP (1P+N) |
| Rated Current | 25A |
| Rated Sensitivity (IΔn) | 300mA |
| Conformance to Standards | IS 12640 (Part 1), IEC/EN 61008-1 |
| Rated Voltage Un | 240V |
| Rated Impulse Withstand Voltage (Uimp) | 4 KV |
| Rated Conditional Short-Circuit Current (Inc) | 6kA |
| IP Category | IP20 (finger proof terminals) |
| ISI Marking | Yes |
| Type | AC |
| Termination | Dual termination, suitable for busbar and/or wire |
| Screws | Combi head screws (standard as well as Philips head screw driver) |
| Test Button | Checks healthiness by creating a virtual electrical fault; recommended to test once every month |
Ordering / Variants
Available in 2 Pole and 4 Pole, 25A / 40A / 63A, 30mA / 100mA / 300mA. A 10kA version is also listed as BCHRCBR300DPC25.
Datasheet, certificates and quotation on request - info@west-velocity.com.
